Mobile Phone GSM Signal Booster / Amplifier EST-GSM970 , High Gain
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | GSM Signal Booster | Frequency Range | Uplink:890—915MHZ Downlink 935-960MHz |
|---|---|---|---|
| Export Power (Po) | ≥23dBm | Pass Band Ripple | ≤3dB |
| Size | 220 X 140 X 40 Mm | Power Supply | AC110～240V 45～55Hz |
| Coverage Area | 1000 M2 | ||
| Highlight | Cell Phone Signal Amplifier,GSM Signal Repeater |
||
Product Description
Mobile Phone GSM Signal Booster / Amplifier EST-GSM970 , High Gain
A mobile phone signal repeater provides the ultimate solution in any area where cellular communications can not work well due to leak of signals. The repeater device features easy installation & operation, build-in indoor antenna and no interference. It could also improve indoor electromagnetism environments, protract cellular battery life and reduce radiation of cellphones. A mobile phone repeater is ideal for house, home, office use.
Introduction To Mobile Phone Signal Repeater |
1. Enhance Mobile Phone |
2. Improve |
3. Reduce |
4. Protract |
5. Economic Building Cost |
6. Easy Operation |
7. Easy Installation |
8. Build-in Power Supply |
The device featured by easy installation & operation and no interference. It is the ideal device for boost mobile phone signal. A mobile phone repeater could also improve indoor ctromagnetism environments, protract cellular battery life and reduce radiation of cellphones.
2. Features |
High gain, easy installation and operation. |
Full-duplex, single-port design, build-in power supply. |
Use ALC technology, adjust extent automatically |
LED Light Working & Signal Condition Indicators |
Big linear power, control intermodulation & scatteration stably |
Dependability stand by GB6993-86 standard |
Compatibility of electromagnetism according with ETS300 609-4 |
CE and RoHs Approved |
Technique
Frequency range | Uplink:890—915MHZ |
Gain ( dB) | Uplink Gp≥60 Downlink Gp≥65 |
Export power (Po) | ≥23dBm |
Pass band ripple | ≤3dB |
I/O impedance | 50Ω/N connector |
Noise figure | ≤4dB |
Transmission Delay | ≤0.5μs |
Ambient temperature | -10℃～60℃ |
Power supply | AC110～240V 45～55Hz |
Size | 220 x 140 x 40 mm |
Reliability | To the GB6993-86 standard |
Electromagnetic | To the ETS300 694-4 standard |
Function | a) Power supply LED denote |
coverage area | 1000 m2 |
Specification sInstallation Sketch Map
Installation Approaches
- Fix up outdoor antenna reception on housetop and point to signal tower.
- Connect outdoor antenna to “outdoor” port in repeater machine through cable.
- Connect indoor antenna(s) to “indoor” port in repeater machine through cable also.
- Plug power adaptor into AC power socket and finish installation.
Technique Supporting
- If still no signal receipt after activated repeater, please check if outdoor antenna point to signal tower or elsewhere have strong signal and check if strength achieve -70DBM.
- If can not call out, please adjust the direction of outdoor antenna.
- If strength is not steady, please check if outdoor & indoor antennas are too close. Please ensure the outdoor and indoor antenna have distance of 20
Accessories
SelectionOutdoor antenna use 7 unit yagi type antenna, indoor antenna use board or rooftop antenna and signal wire use coaxial-cable.
Packing list
Main unit 1pc
Power supply 1pc
User manual 1pc
