Portable Mini 3G Repeaters, Cell Phone Signal Repeater for Office

Place of Origin China
Brand Name EST
Certification CE&ROHS
Model Number EST-Wmini repeater
Minimum Order Quantity 1PC
Packaging Details neutral packing
Delivery Time 1-3 working days
Payment Terms 100% before shipment
Supply Ability 500pcs/week

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Power Supply DC+5V I/O Impedance 50Ω
Ambient Temperature -10~+50℃ Product Name 3G Repeaters
Frequency Range Uplink 1920-1980 Downlink 2110-2170 Pass Band Ripple <6.0dB
Max Gain 45±2dB Gain Adjust Range 43dB~47dB
Highlight

mobile phone signal repeater

,

Cell Phone Signal Amplifier

Leave a Message
Product Description

Portable Mini 3G Repeaters EST-W , Cell Phone Signal Repeater for Office





1. Introduction



 Portable mini Pico mobile phone signal repeater is a new product which is to solve the inconvenience of mobile phone repeater installation. Therefore, there is an immediate solution to amplify mobile phone signal in a small coverage, it is good choice to have one this portable repeater, without installation and carry-on. This is the necessary device in signal blind area of business trip, traveling, home and office etc.



2. Advantage



1. Exquisite appearance:

Adopting disposable molding and injection appearance, beautiful as crafts, small size and easy-taking.



2. Powerful function:

amplifying all kinds of mobile phone signal within 1-30m²and the best assistant for calling.





3. Automatically amplifying mobile phone signal and no testing instrument



1. Automatically adjusting the uplink and downlink gain

The device will automatically check input power and control output power when connection with power supply, it will automatically calculate the gain of downlink to adjust the uplink gain after 5 minutes, keeping the performance of the device system and amplifying balance to achieve adjusting uplink and downlink gain function.



2. Isolation checking function



The device will checking the antenna isolation after connecting with power supply, if the antenna isolation does not meet the device installation requirement, the indication light will indicate timely and automatically control the device to reduce gain until the device does not cause self-excitation, it will protect the safety of repeater and no interference of mobile phone network.



3. Power indication function

The device will automatically check the output power after connecting with power supply and timely indicate to achieve good communication and largest coverage.



4. Automatically installation indication

The device will timely and accurately display isolation, power etc information to guide the user without any testing instrument to smoothly operate and amplify coverage.



  • Technology index



    specification

    Function condition

    Uplink

    Downlink

    Model

    Wmini

    white

    1920-1980

    2110-2170

    Pass band ripple

    <6.0dB

    Max gain

    45±2dB

    Gain Adjust Range

    43dB~47dB

    Max Export

    power

    Uplink

    5±2dBm

    Downlink

    5±2dBm

    AGC

    Automatic gain adjustment range  20dB

    Noise figure(reverse)

    <7dB(Max Gain)

    Inter-Modulation Attenuation

    9KHz~1GHz    ≤-36dBm @ 3KHz

    1GHz~12.75GHz ≤-36dBm@ 3KHz

    Out-of-band spurious emission



    9KHz~1GHz    ≤-36dBm @ 3KHz

    1GHz~12.75GHz ≤-36dBm@ 3KHz

    Transmission delay



    <5us

    VSWR

    <1:2

    Ambient temperature

    -10~+50℃

    Indicator

    ISO red(Isolation testing)

    UP green(uplink power)

    DN green(downlink power)

    Power supply

    DC+5V

    I/O Impedance

    50Ω

    input/output connector

    Base station:SMA

    Built-in





    Application

    1. Residential areas
    2. Villas
    3. All kinds of entertainments, e.g. KTV
    4. Underground bar and coffee house
    5. Small conference room
    6. Signal blind spot of business trip, traveling, home and offices etc.
