Mobile Phone Dual Band Repeater

China Mobile Phone Dual Band Repeater supplier
Mobile Phone Dual Band Repeater supplier Mobile Phone Dual Band Repeater supplier Mobile Phone Dual Band Repeater supplier Mobile Phone Dual Band Repeater supplier

Large Image :  Mobile Phone Dual Band Repeater

Product Details:

Place of Origin: China guangdong
Brand Name: EST
Certification: CE&ROHS
Model Number: EST-GSM/3G repeater

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Packaging Details: neutral packing
Delivery Time: 1-3 working days after received the full payment
Payment Terms: 100% before shipment
Supply Ability: 500pcs/week/J
Contact Now
Detailed Product Description
Features: High Gain / Full-duplex / Single-Port Product Name: Dual Band Repeater
Export Power (Po): ≥27dBm I/O Impedance: 50Ω/N Connector
Size: 220 X180 X 20 Mm Power Supply: AC110~240V 45~55Hz
Coverage Area: 2000 M2 Certifications: CE And RoHs

Mobile Phone Signal Dual Band Amplifier With 2000m2 Boost Coverage Area





1 Quick detailsUplink 890-915MHz 1930-1990MHz      Downlink 935~960MHz  2110-1180MHz

                        Coverage area : 2000m2



Hot sales:

* Provide the ultimate solution in any area where cellular communications can work well due to leak of signals.

* Easy Installation and operation

* Improve indoor electromangetism environments

* Boost mobile phone singal





Are you are faced problem with your mobile network?



We are here to help provide you with a wide range of products that will boost your mobile phone reception to a usable level.

* Hanging out of Windows to make a call?

* Getting cold in the Office car park to make a quick call?

* Suffering with frustrating dropped calls?

* Really slow mobile Internet data speed?

* New contract poor reception and the Mobile network will do nothing to help?

* Tried everything including rubbish antenna stickers from the local market!



The dual band repeater  will resolve all of your problems







2  Specification





Frequency range

Uplink 890-915MHz 1930-1990MHz

Downlink 935~960MHz  2110-1180MHz

Gain ( dB)

Uplink  Gp≥60 Downlink   Gp≥65

Export power (Po)

≥27dBm

Pass band ripple

≤3dB

I/O impedance

50Ω/N connector

Noise figure

≤4dB

Transmission Delay

≤0.5μs

Ambient temperature

-10℃~60℃

Power supply

AC110~240V    45~55Hz

Size

220 x180 x 20 mm

Reliability

To the GB6993-86 standard

Electromagnetic

 compatibility

To the ETS300 694-4 standard

Function

a) Power supply LED denote

b) Export power LED denote

coverage  area

2000 m2







3 Installation Approaches



  1. Fix up outdoor antenna reception on housetop and point to signal tower.
  2. Connect outdoor antenna to “outdoor” port in repeater machine through cable.
  3. Connect indoor antenna(s) to “indoor” port in repeater machine through cable also.
  4. Plug power adaptor into AC power socket and finish installation.





4 Technique Supporting



  1. If still no signal receipt after activated repeater, please check if outdoor antenna point to signal tower or elsewhere have strong signal and check if strength achieve -70DBM.
  2. If can not call out, please adjust the direction of outdoor antenna.
