9 Channels Portable Gun Shape Anti Drone Defense System Designed for Enhanced Security in Sensitive Areas with 2000m Blocking Distance
Product Details
| Dimensions | 710*370*205mm | Weight | About 7.5kg |
|---|---|---|---|
| Jamming Range | 100-2000 Meters | Antenna Type | Built-in Directional Antennas |
| Power Supply | Built-in DC 29.4V 12.5AH Battery | Storage Temperature | -20°C~70°C |
| Jamming Methods | Forced Return, Hover And Signal Scramble | Application | FPV Drones, And Other Kinds Of Anti-drone Device/system |
| Highlight | portable gun shape drone jammer,anti drone defense system 2000m,9 channels UAV jammer security |
||
Product Description
9 Channels Portable Gun Shape Anti Drone Defense System
Product Overview
The Drone UAV Jammer is a cutting-edge security device designed to effectively disrupt unauthorized drone activities, ensuring the safety and privacy of sensitive areas. Utilizing advanced multi-channel jamming technology, this system can target various frequencies simultaneously to neutralize potential drone threats with a blocking distance of up to 2000 meters.
Key Features
- Product Name: Drone UAV Jammer
- Dimensions: 710x370x205mm
- Total Output Power: 180W
- Jamming Radius: 100-2000 Meters (depends on final configuration)
- Antenna Type: Directional Antennas
- Heat Management: Air Cooling System
- Effective Flying FPV Drone Blocker for secure airspace control
- Supports Multi-Channel Drone Jammers for comprehensive signal disruption
- Reliable Anti Drone Defense System ensuring protection against unauthorized UAVs
Technical Specifications
| Dimensions | 710x370x205mm |
| Battery Time | Continuous Working For 30-120 Minutes (depends on final configuration) |
| Storage Temperature | -20°C~70°C |
| Jamming Methods | Forced Return, Hover And Signal Scramble |
| Heat Management | Air Cooling |
| Application | FPV Drones and Other Kinds of Anti-drone Devices/Systems |
| Maximum Power Consumption | 600W (depends on final configuration) |
| Gain | 33dBm-50dBm (depends on final configuration) |
| Total Output Power | 180W (depends on final configuration) |
| Jamming Modes | 5 Modes |
Available Frequency Bands
| Frequency Band | Range | Power |
|---|---|---|
| 433M | 428-468MHz | 10W |
| 900M | 840-960MHz | 10W |
| 1.2G | 1170-1280MHz | 10W |
| 1.4G | 700-840MHz | 10W |
| 1.5G | 1500-1620MHz | 10W |
| 2.4G | 2400-2500MHz | 30W |
| 5.2G | 5150-5350MHz | 30W |
| 5.8G | 5715-5860MHz | 30W |
| 5.5G | 5350-5550MHz | 30W |
Applications
The EST Drone UAV Jammer series provides comprehensive protection against unauthorized drone activities in various critical applications:
- Government buildings and military bases
- Airports and critical infrastructure
- Prisons and correctional facilities
- Large public events and venues
- Tactical security operations
- Private estates and corporate campuses
The system effectively disrupts control signals and GPS navigation, preventing potential threats including espionage, smuggling, and privacy invasion.
Customization Options
EST offers customizable Drone UAV Jammer products under model numbers EST-710, EST-730, EST-750, and EST-700. Each unit features 5 jamming modes and can be equipped with high gain omni spring antennas or directional panel antennas. Custom dimensions are available starting from approximately 390x340x60mm, with flexible order quantities starting from just 1 set. Fast delivery within 3-15 days with supply capacity of up to 800 pieces per week.
